Feature
The main valve is of the spool type that requires no oil lubrication.
A combination of a specially configured packing and a spool enables oilless operation.
Manual button provided as standard.
All types are provided with a manual button.
Easy maintenance.
Long-life products. Engineered with prime importance on ease of maintenance, they are very simple in construction with smaller number of component parts.
Also available as three-way valves.
Four-way valves as standard. They can also be used as three-way valves by plugging one of the two outlets.
Easy to install
Troublesome piping work is unnecessary because the valve can be directly installed to a cylinder by the Namur mount method.
Moreover, the standardized connection configuration enables installation to every cylinder having a Namur mount.
Also connectable to piping.
Connectable to piping as Rc1/4 threads are cut on the inner surface of the O-ring at the outlet side.
Standard specification
- FLUID
- AIR , INERT GAS
- FLUID TEMPERATURE
- -20 ～ 60℃
- AMBIENT TEMPERATURE
- -20 ～ 60℃
- DUTY CYCLE
- 100% CONTINUOUSLY RATED
- OPERATING VOLTAGE RANGE
- +10，-15％
- WORKING PRESSURE
- 0.12 ～ 0.99MPa
- Cv. FLOW FACTOR
- 0.9
- ELECTRICAL SPECIFICATIONS
- See below
ELECTRICAL SPECIFICATIONS
| AC | DC | |||
|---|---|---|---|---|
| V/Hz | INRUSH A | HOLDING A | V | A |
| GENERAL PURPOSE TYPE 12PG, EXPLOSION-PROOF TYPE E12PU | COIL INSULATION CLASS : H | |||
| 100/50 | 0.27 | 0.16 | 24 | 0.33 |
| 100/60 | 0.25 | 0.13 | 48 | 0.15 |
| 110/60 | 0.25 | 0.15 | 100 | 0.072 |
| 200/50 | 0.14 | 0.08 | 110 | 0.08 |
| 200/60 | 0.13 | 0.07 | 125 | 0.06 |
| 220/60 | 0.13 | 0.08 | ||
Product Image
MK15G GENERAL PURPOSE TYPE
| MK15G GENERAL PURPOSE TYPE | ||
|---|---|---|
| NOMINAL DIAMETER | MOUNTING LENGTH | H |
| 8 | 45 | 198 |
MK15G EXPLOSION-PROOF TYPE
| MK15G EXPLOSION-PROOF TYPE | ||
|---|---|---|
| NOMINAL DIAMETER | MOUNTING LENGTH | H |
| 8 | 45 | 214 |
MK15G HYDROGEN EXPLOSION-PROOF TYPE
| MK15G HYDROGEN EXPLOSION-PROOF TYPE | ||
|---|---|---|
| NOMINAL DIAMETER | MOUNTING LENGTH | H |
| 8 | 45 | 211 |
DESCRIPTION OF OPERATION
