Gems Compressor Pressure Switches

Gems Compressor Pressure Switches

PS11 Series Low Pressure Switch

  • 0.75 to 15 psi (.051 to 1 bar)
  • Adjustable or Factory Setpoint
  • 1,000,000 Cycle Life Typical
  • Formerly PDPA/PDPF

PS31/PS51 Series Pressure Switches

  • 5 to 300 psi (.345 to 20 bar)
  • Adjustable or Factory Set
  • Ideal for Low Temperature Pneumatic Applications

2/PS52 Series OEM Pressure Switches

  • 5 to 300 psi (3.45 to 20 bar)
  • Adjustable or Factory Set
  • Ideal for Pneumatic and Low Pressure Hydraulic Applications

PS41 Series Pressure Switch

  • 3.5 to 100 psi (0.24 to 7 bar)
  • Field Adjustable
  • Economical

PS61 Series Hydraulic Pressure Switch

  • 15 to 3000 psi (1 to 207 bar)
  • Adjustable or Factory Set
  • Perfect for Demanding OHV Applications

PS62 Series OEM Pressure Switch

  • 15 to 600 psi (1 to 41 bar)
  • Adjustable or Factory Setpoint
  • Minimal Set Point Change at Low Temperature Extremes

PS71 Series Hydraulic Pressure Switch

  • 10 to 5000 psi (0.7 to 344 bar)
  • Adjustable or Factory Set
  • Multiple Fittings, Electrical Ranges and Terminations

PS72 Series OEM Pressure Sensors

  • 10 to 750 psi (0.7 to 52 bar)
  • Adjustable or Factory Set
  • Minimal Setpoint Change at Low Temperature Extremes

PS75 Series General Purpose Pressure Switch

  • 5 to 6000 psi (0.35 to 414 bar)
  • Wear Disc Design for Longer Life

PS76 Series Pressure Switch

  • 15 to 1750 psi (1 to 121 bar)



Part Number Description Pressure Range Switch TypeSPST, N.O. = Normally Open dry Fitting Type Fitting Material
      SPST, N.C. = Normally Closed dry
      SPDT = Single-pole Double Throw
209542 PS11-20-4MNB-C-FL18 3.5-15 psi SPDT 1/4" MNPT Brass
209737 PS11-10-2MNB-A-FL18 0.75-4 psi SPST 1/8" MNPT Brass
210319 PS11-10-2MNB-C-FL18 0.75-4 psi SPDT 1/8" MNPT Brass
210638 PS11-20-2MNB-C-HC 3.5-15 psi SPDT 1/8" MNPT Brass
210658 PS11-10-2MNB-C-HC 0.75-4 psi SPDT 1/8" MNPT Brass
210687 PS11-20-4MNB-C-HC 3.5-15 psi SPDT 1/4" MNPT Brass
210887 PS11-20-4MNB-C-EL18 3.5-15 psi SPDT 1/4" MNPT Brass
211218 PS11-10-4MGB-C-H 0.75-4 psi SPDT 1/4" BSPM (G Type) Brass
211263 PS11-10-4MGB-C-HC 0.75-4 psi SPDT 1/4" BSPM (G Type) Brass
211264 PS11-20-4MGB-C-HC 3.5-15 psi SPDT 1/4" BSPM (G Type) Brass
212302 PS11-20-4MNB-A-FL18 3.5-15 psi SPST 1/4" MNPT Brass
213118 PS11-20-4MNB-B-FL18 3.5-15 psi SPST 1/4" MNPT Brass
213131 PS11-10-4MNB-C-FL18 0.75-4 psi SPDT 1/4" MNPT Brass
213716 PS11-10-4MNB-C-HC 0.75-4 psi SPDT 1/4" MNPT Brass
215860 PS11-20-2MNB-C-FL18 3.5-15 psi SPDT 1/8" MNPT Brass
215898 PS11-10-4MNB-B-FL18 0.75-4 psi SPST 1/4" MNPT Brass
216016 PS11-10-4MGB-A-FL18 0.75-4 psi SPST 1/4" BSPM (G Type) Brass
216364 PS11-20-4MNB-C-HN 3.5-15 psi SPDT 1/4" MNPT Brass
217066 PS11-10-4MNB-A-EL18 0.75-4 psi SPST 1/4" MNPT Brass
217241 PS11-10-4MNB-C-EL18 0.75-4 psi SPDT 1/4" MNPT Brass
218249 PS11-10-2MNB-B-FL18 0.75-4 psi SPST 1/8" MNPT Brass
218839 PS11-20-4MGB-C-H 3.5-15 psi SPDT 1/4" BSPM (G Type) Brass
220042 PS11-20-4MGB-A-FL18 3.5-15 psi SPST 1/4" BSPM (G Type) Brass
220970 PS11-20-4MSB-C-H 3.5-15 psi SPDT 7/16"-20 SAE Male Brass
221025 PS11-10-4MNB-C-HN 0.75-4 psi SPDT 1/4" MNPT Brass
225526 PS11-10-4MNB-A-FL18 0.75-4 psi SPST 1/4" MNPT Brass
226139 PS11-20-4MNB-C-H 3.5-15 psi SPDT 1/4" MNPT Brass
227081 PS11-20-4MNB-A-EL18 3.5-15 psi SPST 1/4" MNPT Brass
227487 PS11-20-2MNB-B-FL18 0.75-4 psi SPST 1/8" MNPT Brass
229082 PS11-20-2MNB-A-FL18 0.75-4 psi SPST 1/8" MNPT Brass
229719 PS11-20-4MGB-C-FL18 3.5-15 psi SPDT 1/4" BSPM (G Type) Brass
623322 PS11-10-2MNB-A-EL18 0.75-4 psi SPST 1/8" MNPT Brass
623324 PS11-10-2MNB-B-EL18 0.75-4 psi SPST 1/8" MNPT Brass
623326 PS11-10-2MNB-C-EL18 0.75-4 psi SPDT 1/8" MNPT Brass
623327 PS11-10-2MNB-C-H 0.75-4 psi SPDT 1/8" MNPT Brass
623329 PS11-10-2MNB-C-HN 0.75-4 psi SPDT 1/8" MNPT Brass
623333 PS11-10-4MNB-B-EL18 0.75-4 psi SPST 1/4" MNPT Brass
623336 PS11-10-4MNB-C-H 0.75-4 psi SPDT 1/4" MNPT Brass
623349 PS11-10-4MGB-A-EL18 0.75-4 psi SPST 1/4" BSPM (G Type) Brass
623350 PS11-10-4MGB-B-FL18 0.75-4 psi SPST 1/4" BSPM (G Type) Brass
623351 PS11-10-4MGB-B-EL18 0.75-4 psi SPST 1/4" BSPM (G Type) Brass
623352 PS11-10-4MGB-C-FL18 0.75-4 psi SPDT 1/4" BSPM (G Type) Brass
623353 PS11-10-4MGB-C-EL18 0.75-4 psi SPDT 1/4" BSPM (G Type) Brass
623356 PS11-10-4MGB-C-HN 0.75-4 psi SPDT 1/4" BSPM (G Type) Brass
623357 PS11-10-4MSB-A-FL18 0.75-4 psi SPST 7/16"-20 SAE Male Brass
623358 PS11-10-4MSB-A-EL18 0.75-4 psi SPST 7/16"-20 SAE Male Brass
623359 PS11-10-4MSB-B-FL18 0.75-4 psi SPST 7/16"-20 SAE Male Brass
623360 PS11-10-4MSB-B-EL18 0.75-4 psi SPST 7/16"-20 SAE Male Brass
623361 PS11-10-4MSB-C-FL18 0.75-4 psi SPDT 7/16"-20 SAE Male Brass
623362 PS11-10-4MSB-C-EL18 0.75-4 psi SPDT 7/16"-20 SAE Male Brass

623363 PS11-10-4MSB-C-H 0.75-4 psi SPDT 7/16"-20 SAE Male Brass
623364 PS11-10-4MSB-C-HC 0.75-4 psi SPDT 7/16"-20 SAE Male Brass
623365 PS11-10-4MSB-C-HN 0.75-4 psi SPDT 7/16"-20 SAE Male Brass
623367 PS11-20-2MNB-A-EL18 0.75-4 psi SPST 1/8" MNPT Brass
623369 PS11-20-2MNB-B-EL18 3.5-15 psi SPST 1/8" MNPT Brass
623371 PS11-20-2MNB-C-EL18 3.5-15 psi SPDT 1/8" MNPT Brass
623372 PS11-20-2MNB-C-H 3.5-15 psi SPDT 1/8" MNPT Brass
623374 PS11-20-2MNB-C-HN 3.5-15 psi SPDT 1/8" MNPT Brass
623378 PS11-20-4MNB-B-EL18 3.5-15 psi SPST 1/4" MNPT Brass
623394 PS11-20-4MGB-A-EL18 3.5-15 psi SPST 1/4" BSPM (G Type) Brass
623395 PS11-20-4MGB-B-FL18 3.5-15 psi SPST 1/4" BSPM (G Type) Brass
623396 PS11-20-4MGB-B-EL18 3.5-15 psi SPST 1/4" BSPM (G Type) Brass
623398 PS11-20-4MGB-C-EL18 3.5-15 psi SPDT 1/4" BSPM (G Type) Brass
623401 PS11-20-4MGB-C-HN 3.5-15 psi SPDT 1/4" BSPM (G Type) Brass
623402 PS11-20-4MSB-A-FL18 3.5-15 psi SPST 7/16"-20 SAE Male Brass
623403 PS11-20-4MSB-A-EL18 3.5-15 psi SPST 7/16"-20 SAE Male Brass
623404 PS11-20-4MSB-B-FL18 3.5-15 psi SPST 7/16"-20 SAE Male Brass
623405 PS11-20-4MSB-B-EL18 3.5-15 psi SPST 7/16"-20 SAE Male Brass
623406 PS11-20-4MSB-C-FL18 3.5-15 psi SPDT 7/16"-20 SAE Male Brass
623407 PS11-20-4MSB-C-EL18 3.5-15 psi SPDT 7/16"-20 SAE Male Brass
623410 PS11-20-4MSB-C-HN 3.5-15 psi SPDT 7/16"-20 SAE Male Brass

193660 PS61-19-4MNS-A-SP 75-275 psi SPST 1/4" MNPT 316 Stainless Steel
201019 PS41-20-4MNB-C-HCR 7-30 psi SPDT 1/4" MNPT Brass
204618 PS75-50-4MNS-C-HC 500-1750 psi SPDT 1/4" MNPT 316 Stainless Steel
204626 PS41-30-4MNS-C-H 25-100 psi SPDT 1/4" MNPT 316 Stainless Steel
204631 PS41-10-2MNB-C-FL18 3.5-8 psi SPDT 1/8" MNPT Brass
204638 PS41-30-4MNS-C-HN 25-100 psi SPDT 1/4" MNPT 316 Stainless Steel
204656 PS75-50-4SSZ-C-H 500-1750 psi SPDT 7/16"-20 SAE Male Swivel 12L14 Zinc-Plated Steel
204657 PS71-20-2MNZ-C-FL18 25-75 psi SPDT 1/8" MNPT 12L14 Zinc-Plated Steel
204661 PS71-40-4MNZ-A-FL18 250-1000 psi SPST 1/4" MNPT 12L14 Zinc-Plated Steel
204671 PS75-30-4MNZ-C-H 50-150 psi SPDT 1/4" MNPT 12L14 Zinc-Plated Steel
204674 PS71-40-4MNZ-C-HC 250-1000 psi SPDT 1/4" MNPT 12L14 Zinc-Plated Steel
204678 PS81-10-4MGB-C-HC 1.5-5" Hg SPDT 1/4" BSPM (G Type) Brass
204679 PS71-40-4MGZ-A-FL18 250-1000 psi SPST 1/4" BSPM (G Type) 12L14 Zinc-Plated Steel
204680 PS75-50-4MSZ-C-HR 500-1750 psi SPDT 7/16"-20 SAE Male 12L14 Zinc-Plated Steel
204684 PS41-10-4MGB-C-HC 3.5-8 psi SPDT 1/4" BSPM (G Type) Brass
204685 PS31-40-2MNB-B-SP 50-150 psi SPST 1/8" MNPT Brass
204689 PS75-40-4MGZ-C-HCR 150-650 psi SPDT 1/4" BSPM (G Type) 12L14 Zinc-Plated Steel
204692 PS82-10-4MNS-C-HC 5-15" Hg SPDT 1/4" MNPT 316 Stainless Steel
204695 PS31-40-2MNB-B-FL18 50-150 psi SPST 1/8" MNPT Brass
206510 PS75-20-4MGZ-C-H 15-75 psi SPDT 1/4" BSPM (G Type) 12L14 Zinc-Plated Steel
206544 PS75-50-4MSZ-C-HC 500-1750 psi SPDT 7/16"-20 SAE Male 12L14 Zinc-Plated Steel
206569 PS31-40-4MNB-B-SP 50-150 psi SPST 1/4" MNPT Brass
206574 PS61-50-4MGZ-A-SP 1000-3000 psi SPST 1/4" BSPM (G Type) 12L14 Zinc-Plated Steel
206577 PS41-30-2MNB-C-HCR 25-100 psi SPDT 1/8" MNPT Brass
206592 PS41-30-4MNB-C-H 25-100 psi SPDT 1/4" MNPT Brass
206599 PS61-50-4MNZ-A-SP 1000-3000 psi SPST 1/4" MNPT 12L14 Zinc-Plated Steel
206630 PS52-15-2MNB-A-SP 50-150 psi SPST 1/8" MNPT Brass
207669 PS75-60-4MNZ-C-HR 1000-3500 psi SPDT 1/4" MNPT 12L14 Zinc-Plated Steel
207673 PS41-20-2MNB-A-FL18 7-30 psi SPST 1/8" MNPT Brass
207678 PS31-20-2MNB-A-SP 5-25 psi SPST 1/8" MNPT Brass
207686 PS41-30-4MNB-C-HN 25-100 psi SPDT 1/4" MNPT Brass
207690 PS75-70-4MNZ-C-HNR 2500-6000 psi SPDT 1/4" MNPT 12L14 Zinc-Plated Steel
207694 PS71-40-4MNZ-C-H 250-1000 psi SPDT 1/4" MNPT 12L14 Zinc-Plated Steel
207927 PS75-70-4SSZ-C-HCR 2500-6000 psi SPDT 7/16"-20 SAE Male Swivel 12L14 Zinc-Plated Steel
208680 PS71-30-2MNZ-C-FL18 65-300 psi SPDT 1/8" MNPT 12L14 Zinc-Plated Steel
209013 PS32-40-2MGB-A-TS 50-150 psi SPST 1/8" BSPM (G Type) Brass
209018 PS41-20-4MNB-C-HC 7-30 psi SPDT 1/4" MNPT Brass
209077 PS31-20-2MNB-B-SP 5-25 psi SPST 1/8" MNPT Brass
209130 PS71-50-4MNZ-C-FL18 1000-3000 psi SPDT 1/4" MNPT 12L14 Zinc-Plated Steel
209146 PS41-30-2MNB-C-HC 25-100 psi SPDT 1/8" MNPT Brass
209152 PS75-60-4MNZ-C-HNR 1000-3500 psi SPDT 1/4" MNPT 12L14 Zinc-Plated Steel
209157 PS71-50-4MSZ-C-H 1000-3000 psi SPDT 7/16"-20 SAE Male 12L14 Zinc-Plated Steel
209159 PS41-30-4MNB-C-HC 25-100 psi SPDT 1/4" MNPT Brass
209161 PS75-50-4MNZ-C-H 500-1750 psi SPDT 1/4" MNPT 12L14 Zinc-Plated Steel
209166 PS71-20-4MNZ-C-HC 25-75 psi SPDT 1/4" MNPT 12L14 Zinc-Plated Steel
