SIEMENS temperature Flow Measurement coriolis transmitter SIFLOW FC070

With SIFLOW FC070 Siemens has developed the first flow transmitter designed for direct integration into SIMATIC S7 and SIMATIC PCS7 automation systems. SIFLOW FC070 is a true multiparameter Coriolis mass flow transmitter covering the full repertoire within flow applications and industries, ready for quick installation and system integration. SIFLOW FC070 is suitable for any application in automated industries where there is a demand for accurate flow measurement.The SIFLOW FC070 Ex CT is custody transfer approved for high pressure natural gas used in CNG dispencers.

In order to make a complete flowmeter, the SIFLOW FC070 transmitter can be combined with one of the following MASS sensors

SITRANS F C MASS 2100 DI 1.5: For low flow applications
SITRANS FC300 DN 4: For low flow applications
SITRANS F C MASS 2100 DI 3-40: Mass flow measurement for general industry
SITRANS F C MC2: Suitable for Food & Beverage applications
SITRANS FCS200: For measurement of gases.

Benefits

• Direct integration into SIMATIC S7 automation system

• Standardized user interface – SIMATIC Manager, PCS7, SIMATIC PDM

• Ultra compact, cost-effective and space-saving design captured in a 40/80 mm enclosure

• Built-in totalizers, batch controller and comprehensive process diagnostics

• SENSORPROM enables true  Plug & Play  functionality

Detail

Accuracy, mass flow	±0.1% of mass flow rate
Outputs	Pulse - Redundancy phase shiftet 90° / 180° Frequency - Redundancy phase shiftet 90° / 180° 2-stage batch
Communication	SIMATIC PBUS (backplane) Profibus DP (via ET200M) Profinet (via ET200M) MODBUS RTU R232C/485
Enclosure Rating	40 mm S7-300 (standard version) 80 mm S7-300 (Ex CT version)
Ambient temperature	0 °C .. 60 C (32°F to 140 F°) For SIFLOW FC070 Ex CT: -40 °C ... 60 °C (-40°F to 140 F°)
Approvals standard version	CE cULusS ATEX II 3 G EEx nA II T4
Approvals Ex version	CE cULus FM Class I, Div. 2 Groups A,B,C,D ATEX II (1)G [Ex ia] IIC Ga ATEX II 3G Ex nA IIC T4 Gc Namur NE21 and VDE2650 IEC Ex (Ex nA [ia] IIC T4) NEPSI: Ex nA IIC T4 Gc
Approvals Custody transfer (CT)	PTB: (Physikalisch-Technische Bundesanstalt) in Germany For high pressure natural gas
