SIEMENS temperature measurement Temperature Sensors SITRANS TS200

The temperature sensor line is equipped with direct mount connectors (M12, Lemo usw.). With its construction based on mineral insulated cable (MIC) supports a wide range of applications. Due to compession fittings or soldering nipples the installation is simple and flexible. With the optional surface adapter the measuring of surface temperature are supported.

The certificate for intrinsic safety allows the operation even in Zone 0 without the need of additional thermowell. This application grands an outstanding reaction time.

Output direct sensor signal
Max. operaton temperature
-measuring point   - cable end
Pt 100 Basic: -30...+400°C

Pt 100 Extended: -196...+600°C

Thermo couple -196...+1100°C

(Depends on type)

-40°...+80°C Ingress protection
 IP54

Benefits

• Universal use for a wide range of applications

• Variety due modular concept

• ATEX and IEC EX-approvals, designed for use in Zone 0
