Features
- Normally closed
- Pilot operated
- Bronze, stainless steel body
Applications
- Spraying. Irrigation. Dishwashers
- Air dryers. Water treatment. Vacuum systems
- Pumps of re-circulation for cold or hot water
- Heating with low or high pressure steam
Item # Body Material Port Size Operating Pressure Max. Temperature Orifice Size Seat Material Voltage
1314BA06AT-12VDC Brass 3/4 in 0-105 psig 176 ºF 19 in Buna N 12 VDC
0-7 bar 80 ºC .75 mm
1314BN06AT-12VDC Brass 3/4 in 0-105 psig 176 ºF 19 in Neoprene 12 VDC
0-7 bar 80 ºC .75 mm
1314BE06AT-12VDC Brass 3/4 in 0-105 psig 302 ºF 19 in EPDM 12 VDC
0-7 bar 150 ºC .75 mm
1314BV06AT-12VDC Brass 3/4 in 0-105 psig 302 ºF 19 in FKM 12 VDC
0-7 bar 150 ºC .75 mm
1314BST06AT-12VDC Brass 3/4 in 0-105 psig 356 ºF 19 in PTFE 12 VDC
0-7 bar 180 ºC .75 mm
1314BA06T-12VDC Brass 3/4 in 1.5-150 psig 176 ºF 19 in Buna N 12 VDC
0.1-10 bar 80 ºC .75 mm
1314BN06T-12VDC Brass 3/4 in 1.5-150 psig 176 ºF 19 in Neoprene 12 VDC
0.1-10 bar 80 ºC .75 mm
1314BE06T-12VDC Brass 3/4 in 1.5-150 psig 302 ºF 19 in EPDM 12 VDC
0.1-10 bar 150 ºC .75 mm
1314BV06T-12VDC Brass 3/4 in 1.5-150 psig 302 ºF 19 in FKM 12 VDC
0.1-10 bar 150 ºC .75 mm
1314BST06T-12VDC Brass 3/4 in 1.5-150 psig 356 ºF 19 in PTFE 12 VDC
0.1-10 bar 180 ºC .75 mm
1314BA08AT-12VDC Brass 1 in 0-105 psig 176 ºF 26 in Buna N 12 VDC
0-7 bar 80 ºC 1.02 mm
1314BN08AT-12VDC Brass 1 in 0-105 psig 176 ºF 26 in Neoprene 12 VDC
0-7 bar 80 ºC 1.02 mm
1314BE08AT-12VDC Brass 1 in 0-105 psig 302 ºF 26 in EPDM 12 VDC
0-7 bar 150 ºC 1.02 mm
1314BV08AT-12VDC Brass 1 in 0-105 psig 302 ºF 26 in FKM 12 VDC
0-7 bar 150 ºC 1.02 mm
1314BST08AT-12VDC Brass 1 in 0-105 psig 356 ºF 26 in PTFE 12 VDC
0-7 bar 180 ºC 1.02 mm
1314BA08T-12VDC Brass 1 in 1.5-150 psig 176 ºF 26 in Buna N 12 VDC
0.1-10 bar 80 ºC 1.02 mm
1314BN08T-12VDC Brass 1 in 1.5-150 psig 176 ºF 26 in Neoprene 12 VDC
0.1-10 bar 80 ºC 1.02 mm
1314BE08T-12VDC Brass 1 in 1.5-150 psig 302 ºF 26 in EPDM 12 VDC
0.1-10 bar 150 ºC 1.02 mm
1314BV08T-12VDC Brass 1 in 1.5-150 psig 302 ºF 26 in FKM 12 VDC
0.1-10 bar 150 ºC 1.02 mm
1314BST08T-12VDC Brass 1 in 1.5-150 psig 356 ºF 26 in PTFE 12 VDC
0.1-10 bar 180 ºC 1.02 mm
1314BA12T-12VDC Brass 1 1/2 in 0-105 psig 176 ºF 32 in Buna N 12 VDC
0-7 bar 80 ºC 1.26 mm
1314BN12T-12VDC Brass 1 1/2 in 0-105 psig 176 ºF 32 in Neoprene 12 VDC
0-7 bar 80 ºC 1.26 mm
1314BE12T-12VDC Brass 1 1/2 in 0-105 psig 302 ºF 32 in EPDM 12 VDC
0-7 bar 150 ºC 1.26 mm
1314BV12T-12VDC Brass 1 1/2 in 0-105 psig 302 ºF 32 in FKM 12 VDC
0-7 bar 150 ºC 1.26 mm
1314BST12T-12VDC Brass 1 1/2 in 0-105 psig 356 ºF 32 in PTFE 12 VDC
0-7 bar 180 ºC 1.26 mm
1314BN12AT-12VDC Brass 1 1/2 in 1.5-150 psig 176 ºF 32 in Neoprene 12 VDC
0.1-10 bar 80 ºC 1.26 mm
1314BE12AT-12VDC Brass 1 1/2 in 1.5-150 psig 302 ºF 32 in EPDM 12 VDC
0.1-10 bar 150 ºC 1.26 mm
1314BV12AT-12VDC Brass 1 1/2 in 1.5-150 psig 302 ºF 32 in FKM 12 VDC
0.1-10 bar 150 ºC 1.26 mm
1314BST12AT-12VDC Brass 1 1/2 in 1.5-150 psig 356 ºF 32 in PTFE 12 VDC
0.1-10 bar 180 ºC 1.26 mm
1314BA16AT-12VDC Brass 2 in 0-105 psig 176 ºF 38 in Buna N 12 VDC
0-7 bar 80 ºC 1.5 mm
1314BN16AT-12VDC Brass 2 in 0-105 psig 176 ºF 38 in Neoprene 12 VDC
0-7 bar 80 ºC 1.5 mm
1314BE16AT-12VDC Brass 2 in 0-105 psig 302 ºF 38 in EPDM 12 VDC
0-7 bar 150 ºC 1.5 mm
1314BV16AT-12VDC Brass 2 in 0-105 psig 302 ºF 38 in FKM 12 VDC
0-7 bar 150 ºC 1.5 mm
1314BST16AT-12VDC Brass 2 in 0-105 psig 356 ºF 38 in PTFE 12 VDC
0-7 bar 180 ºC 1.5 mm
1314BA16T-12VDC Brass 2 in 1.5-150 psig 176 ºF 38 in Buna N 12 VDC
0.1-10 bar 80 ºC 1.5 mm
1314BN16T-12VDC Brass 2 in 1.5-150 psig 176 ºF 38 in Neoprene 12 VDC
0.1-10 bar 80 ºC 1.5 mm
1314BE16T-12VDC Brass 2 in 1.5-150 psig 302 ºF 38 in EPDM 12 VDC
0.1-10 bar 150 ºC 1.5 mm
1314BV16T-12VDC Brass 2 in 1.5-150 psig 302 ºF 38 in FKM 12 VDC
0.1-10 bar 150 ºC 1.5 mm
1314BST16T-12VDC Brass 2 in 1.5-150 psig 356 ºF 38 in PTFE 12 VDC
0.1-10 bar 180 ºC 1.5 mm
1314SA06AT-12VDC Stainless Steel 3/4 in 0-105 psig 176 ºF 19 in Buna N 12 VDC
0-7 bar 80 ºC .75 mm
1314SN06AT-12VDC Stainless Steel 3/4 in 0-105 psig 176 ºF 19 in Neoprene 12 VDC
0-7 bar 80 ºC .75 mm
1314SE06AT-12VDC Stainless Steel 3/4 in 0-105 psig 302 ºF 19 in EPDM 12 VDC
0-7 bar 150 ºC .75 mm
1314SV06AT-12VDC Stainless Steel 3/4 in 0-105 psig 302 ºF 19 in FKM 12 VDC
0-7 bar 150 ºC .75 mm
1314STT06AT-12VDC Stainless Steel 3/4 in 0-105 psig 356 ºF 19 in PTFE 12 VDC
0-7 bar 180 ºC .75 mm
1314SA06T-12VDC Stainless Steel 3/4 in 1.5-150 psig 176 ºF 19 in Buna N 12 VDC
0.1-10 bar 80 ºC .75 mm
1314SN06T-12VDC Stainless Steel 3/4 in 1.5-150 psig 176 ºF 19 in Neoprene 12 VDC
0.1-10 bar 80 ºC .75 mm
1314SE06T-12VDC Stainless Steel 3/4 in 1.5-150 psig 302 ºF 19 in EPDM 12 VDC
0.1-10 bar 150 ºC .75 mm
1314SV06T-12VDC Stainless Steel 3/4 in 1.5-150 psig 302 ºF 19 in FKM 12 VDC
0.1-10 bar 150 ºC .75 mm
1314ST06T-12VDC Stainless Steel 3/4 in 1.5-150 psig 356 ºF 19 in PTFE 12 VDC
0.1-10 bar 180 ºC .75 mm
1314SA08AT-12VDC Stainless Steel 1 in 0-105 psig 176 ºF 26 in Buna N 12 VDC
0-7 bar 80 ºC 1.02 mm
1314SN08AT-12VDC Stainless Steel 1 in 0-105 psig 176 ºF 26 in Neoprene 12 VDC
0-7 bar 80 ºC 1.02 mm
1314SE08AT-12VDC Stainless Steel 1 in 0-105 psig 302 ºF 26 in EPDM 12 VDC
0-7 bar 150 ºC 1.02 mm
1314SV08AT-12VDC Stainless Steel 1 in 0-105 psig 302 ºF 26 in FKM 12 VDC
0-7 bar 150 ºC 1.02 mm
1314ST08AT-12VDC Stainless Steel 1 in 0-105 psig 356 ºF 26 in PTFE 12 VDC
0-7 bar 180 ºC 1.02 mm
1314SA08T-12VDC Stainless Steel 1 in 1.5-150 psig 176 ºF 26 in Buna N 12 VDC
0.1-10 bar 80 ºC 1.02 mm
1314SN08T-12VDC Stainless Steel 1 in 1.5-150 psig 176 ºF 26 in Neoprene 12 VDC
0.1-10 bar 80 ºC 1.02 mm
1314SE08T-12VDC Stainless Steel 1 in 1.5-150 psig 302 ºF 26 in EPDM 12 VDC
0.1-10 bar 150 ºC 1.02 mm
1314SV08T-12VDC Stainless Steel 1 in 1.5-150 psig 302 ºF 26 in FKM 12 VDC
0.1-10 bar 150 ºC 1.02 mm
1314ST08T-12VDC Stainless Steel 1 in 1.5-150 psig 356 ºF 26 in PTFE 12 VDC
0.1-10 bar 180 ºC 1.02 mm
1314SA12T-12VDC Stainless Steel 1 1/2 in 0-105 psig 176 ºF 32 in Buna N 12 VDC
0-7 bar 80 ºC 1.26 mm
1314SN12T-12VDC Stainless Steel 1 1/2 in 0-105 psig 176 ºF 32 in Neoprene 12 VDC
0-7 bar 80 ºC 1.26 mm
1314SE12T-12VDC Stainless Steel 1 1/2 in 0-105 psig 302 ºF 32 in EPDM 12 VDC
0-7 bar 150 ºC 1.26 mm
1314SV12T-12VDC Stainless Steel 1 1/2 in 0-105 psig 302 ºF 32 in FKM 12 VDC
0-7 bar 150 ºC 1.26 mm
1314ST12T-12VDC Stainless Steel 1 1/2 in 0-105 psig 356 ºF 32 in PTFE 12 VDC
0-7 bar 180 ºC 1.26 mm
1314SA12AT-12VDC Stainless Steel 1 1/2 in 1.5-150 psig 176 ºF 32 in Buna N 12 VDC
0.1-10 bar 80 ºC 1.26 mm
1314SN12AT-12VDC Stainless Steel 1 1/2 in 1.5-150 psig 176 ºF 32 in Neoprene 12 VDC
0.1-10 bar 80 ºC 1.26 mm
1314SE12AT-12VDC Stainless Steel 1 1/2 in 1.5-150 psig 302 ºF 32 in EPDM 12 VDC
0.1-10 bar 150 ºC 1.26 mm
1314SV12AT-12VDC Stainless Steel 1 1/2 in 1.5-150 psig 302 ºF 32 in FKM 12 VDC
0.1-10 bar 150 ºC 1.26 mm
1314ST12AT-12VDC Stainless Steel 1 1/2 in 1.5-150 psig 356 ºF 32 in PTFE 12 VDC
0.1-10 bar 180 ºC 1.26 mm
1314SA16AT-12VDC Stainless Steel 2 in 0-105 psig 176 ºF 38 in Buna N 12 VDC
0-7 bar 80 ºC 1.5 mm
1314SN16AT-12VDC Stainless Steel 2 in 0-105 psig 176 ºF 38 in Neoprene 12 VDC
0-7 bar 80 ºC 1.5 mm
1314SE16AT-12VDC Stainless Steel 2 in 0-105 psig 302 ºF 38 in EPDM 12 VDC
0-7 bar 150 ºC 1.5 mm
1314SV16AT-12VDC Stainless Steel 2 in 0-105 psig 302 ºF 38 in FKM 12 VDC
0-7 bar 150 ºC 1.5 mm
1314ST16AT-12VDC Stainless Steel 2 in 0-105 psig 356 ºF 38 in PTFE 12 VDC
0-7 bar 180 ºC 1.5 mm
1314SA16T-12VDC Stainless Steel 2 in 1.5-150 psig 176 ºF 38 in Buna N 12 VDC
0.1-10 bar 80 ºC 1.5 mm
1314SN16T-12VDC Stainless Steel 2 in 1.5-150 psig 176 ºF 38 in Neoprene 12 VDC
0.1-10 bar 80 ºC 1.5 mm
1314SE16T-12VDC Stainless Steel 2 in 1.5-150 psig 302 ºF 38 in EPDM 12 VDC
0.1-10 bar 150 ºC 1.5 mm
1314SV16T-12VDC Stainless Steel 2 in 1.5-150 psig 302 ºF 38 in FKM 12 VDC
0.1-10 bar 150 ºC 1.5 mm
1314ST16T-12VDC Stainless Steel 2 in 1.5-150 psig 356 ºF 38 in PTFE 12 VDC
0.1-10 bar 180 ºC 1.5 mm
1314BN08T-24VAC Brass 1 in 1.5-225 psig 176 ºF 26 in Neoprene 24 VAC
0.1-15 bar 80 ºC 1.02 mm
1314BA06AT-24VDC Brass 3/4 in 0-105 psig 176 ºF 19 in Buna N 24 VDC
0-7 bar 80 ºC .75 mm
1314BN06AT-24VDC Brass 3/4 in 0-105 psig 176 ºF 19 in Neoprene 24 VDC
0-7 bar 80 ºC .75 mm
1314BE06AT-24VDC Brass 3/4 in 0-105 psig 302 ºF 19 in EPDM 24 VDC
0-7 bar 150 ºC .75 mm
1314BV06AT-24VDC Brass 3/4 in 0-105 psig 302 ºF 19 in FKM 24 VDC
0-7 bar 150 ºC .75 mm
1314BST06AT-24VDC Brass 3/4 in 0-105 psig 356 ºF 19 in PTFE 24 VDC
0-7 bar 180 ºC .75 mm
1314BA06T-24VDC Brass 3/4 in 1.5-150 psig 176 ºF 19 in Buna N 24 VDC
0.1-10 bar 80 ºC .75 mm
1314BN06T-24VDC Brass 3/4 in 1.5-150 psig 176 ºF 19 in Neoprene 24 VDC
0.1-10 bar 80 ºC .75 mm
1314BE06T-24VDC Brass 3/4 in 1.5-150 psig 302 ºF 19 in EPDM 24 VDC
0.1-10 bar 150 ºC .75 mm
1314BV06T-24VDC Brass 3/4 in 1.5-150 psig 302 ºF 19 in FKM 24 VDC
0.1-10 bar 150 ºC .75 mm
1314BST06T-24VDC Brass 3/4 in 1.5-150 psig 356 ºF 19 in PTFE 24 VDC
0.1-10 bar 180 ºC .75 mm
1314BA08AT-24VDC Brass 1 in 0-105 psig 176 ºF 26 in Buna N 24 VDC
0-7 bar 80 ºC 1.02 mm
1314BN08AT-24VDC Brass 1 in 0-105 psig 176 ºF 26 in Neoprene 24 VDC
0-7 bar 80 ºC 1.02 mm
1314BE08AT-24VDC Brass 1 in 0-105 psig 302 ºF 26 in EPDM 24 VDC
0-7 bar 150 ºC 1.02 mm
1314BV08AT-24VDC Brass 1 in 0-105 psig 302 ºF 26 in FKM 24 VDC
0-7 bar 150 ºC 1.02 mm
1314BST08AT-24VDC Brass 1 in 0-105 psig 356 ºF 26 in PTFE 24 VDC
0-7 bar 180 ºC 1.02 mm
1314BA08T-24VDC Brass 1 in 1.5-150 psig 176 ºF 26 in Buna N 24 VDC
0.1-10 bar 80 ºC 1.02 mm
1314BN08T-24VDC Brass 1 in 1.5-150 psig 176 ºF 26 in Neoprene 24 VDC
0.1-10 bar 80 ºC 1.02 mm
1314BE08T-24VDC Brass 1 in 1.5-150 psig 302 ºF 26 in EPDM 24 VDC
0.1-10 bar 150 ºC 1.02 mm
1314BV08T-24VDC Brass 1 in 1.5-150 psig 302 ºF 26 in FKM 24 VDC
0.1-10 bar 150 ºC 1.02 mm
|
