Rotex solenoid valve Engineered Valves MANUAL RESET OFF SOLENOID VALVE

FEATURES :

  1. Valve operated when solenoid is energized.
  2. Valve retains the position when power to the solenoid is removed.
  3. Most of the valves are reset by turning knob clockwise when power to the solenoid is switched off.
  4. Wide varieties of 2 - 3 ports valve can be supplied.
  5. Continuous duty rated solenoid.
  6. Can be supplied with most voltage, current.
  7. Can be supplied with weather proof / Explosion proof solenoid.

Ambient / Fluid Temperature : - 20 °C    to     80 °C

Media :

Air, Inert Gases, Water, Oil

Application:

Manual reset OFF valve (latching on de-energization) switches ON when energized.
Valve does not switch OFF when de-energized till switched OFF manually.
This type of valve is used where the valve is required to remain ON even though supply to the solenoid is switched OFF.

Eg. Firefighting, Clamping, Blow Down application etc.

VALVE TYPE :




Valve Type

 Model No.

 2 PORT DIRECT ACTING NORMALLY CLOSED SOLENOID
 VALVE

 L2001

 2 PORT INTERNAL PILOT OPERATED NORMALLY CLOSED
 SOLENOID VALVE

 L2002

 3 PORT 2 POSITIONS DIRECT ACTING NORMALLY OPEN
 SOLENOID VALVE

 L3015
 L3001

 3 PORT 2 POSITIONS UNIVERSAL SOLENOID VALVE

 L3002

 3 PORT 2 POSITIONS DIRECT ACTING NORMALLY CLOSED
 SOLENOID VALVE

 L3003

 3 PORT 2 POSITIONS UNIVERSAL DIRECT ACTING HIGH
 ORIFICE SOLENOID VALVE

 L3004
 L3005

 3 PORT 2 POSITIONS INTERNAL PILOT OPERATED
 NORMALLY  CLOSED SOLENOID VALVE

 L3006

 3 PORT 2 POSITIONS INTERNAL PILOT OPERATED
 NORMALLY OPEN SOLENOID VALVE

 L3007

 3 PORT 2 POSITIONS UNIVERSAL EXTERNAL PILOT OPERATED SOLENOID VALVE

 L3016

 3 PORT 2 POSITIONS UNIVERSAL INTERNAL PILOT
 OPERATED SOLENOID VALVE

 L3020
