Features:
- Bubble tight shut off.
- Mounts in any position.
- Vibration resistance to 9g.
- Suitable for high speed cycling.
- Speed up to 600 cycles/ min.
- Life >10 million cycles.
SPECIFICATIONS :
|
Model No.
|
Pressure Range
|
Valve Condition
|
|
23102
|
0 - 20 bar
|
Normally Closed
|
|
23201
|
0 - 20 bar
|
Normally Open
|
| Type |
2 Port , 2 Positions |
| Orifice Size |
12, 20, 25, 40, 50 mm |
| Fluid / Ambient Temp |
- 20 °C to 80 °C |
| Body Material |
Powder Coated Aluminium Cast / CF8M,
Brass, CF8M
|
| Spring |
SS 302 |
| Seat, Seals |
NBR, Viton |
| Fasteners |
SS 304 |
Media :
Air, Inert Gases, Water, Vacuum, Free Flowing Liquid,
Oil, Diesel, Kerosene, LPG, Furnace Oil
Applications :
Ideally suited for ON/ OFF control of fuel gas
* The External Air Pressure should be minimum 2 bar or >_ main fluid pressure whichever is higher.
|
