Features :
- Bubble tight shut off.
- Vibration resistance to 9g.
- Suitable for high speed cycling.
- Speed up to 400 cycles/ min.
- Life >10 million cycles.
SPECIFICATIONS :
|
Model No.
|
Pressure Range
|
Valve Condition
|
|
23103
|
0 - 20 bar
|
Normally Closed
|
|
23203
|
0 - 20 bar
|
Normally Open
|
| Type |
2 Port, 2 Position |
| Orifice Size |
12, 20, 25, 40, 50 mm |
| Fluid / Ambient Temp |
- 20 °C to 80 °C |
|
Operating Voltage :
A.C :
D.C :
|
24, 110, 220, 240 (50 Hz / 60 Hz)
6, 12, 24, 48, 72, 110, 220
|
|
Power Consumption :
Size 1 coil :
Size 2 coil :
|
6 W
11 W |
| Body Material |
Powder Coated Die-Cast Aluminium,
CF8M, Brass |
| Guide Assembly |
SS 304 |
| Plunger, Insert |
SS 430 |
| Shadow Ring |
Copper / Silver / None |
| Spring |
SS 302 |
| Seat, Seals |
NBR, Viton, EPDM |
| Fasteners |
SS 304 |
Enclosure:
1. General Purpose Flying lead / Plug-in
2. Weather-Proof: Flying lead & Plug in type, Terminal Box as per IS 13947
3. Explosion-Proof with Junction box as per IS 2148 group I, IIA, IIB and IIC
4. Explosion-Proof with Junction box as per ATEX, INMETRO, CE and UL
in process) available
Media :
Air, Inert Gases, Water, Vacuum, Free Flowing Liquid,
Oil, Diesel, Kerosene, LPG, Furnace Oil
Applications :
Fuel line suit off Vacuum Breaking
* External Pilot pressure should be minimum 2 bar or main fluid pressure whichever is higher.
|
