ASCO RedHat Solenoid Valves 3-Way 8320Q Series

20 million cycle capability – 1/8″–1/4″
Direct acting poppet valves available in normally closed, normally open, and universal constructions. Available AC operated with brass bodies. All pipe connections in valve body to facilitate in-line piping.

pare Coil Part Number
Standard
AC General PurposeExplosionproof
Coil and
Class of DC VA VA
Insulation Watts Watts Holding InrushACAC
F 15.1 22 22 270110 270114
Standard Voltages: 24, 120, 240, 480 volts AC, 60 Hz (or 110, 220 volts AC, 50 Hz).
Must be specified when ordering.
Consult your local ASCO sales office for DC voltages.
Note:
SPECIAL
SERVICE VALVES
8215
Solenoid Enclosures
Nominal Ambient Temp. Ranges
Standard: Watertight, Types 1, 2, 3, 3S, 4, and 4X.
Series 8262: 32F to 131F (0C to 55C)*
Optional: Explosionproof and Watertight, Types 3, 3S, 4, 4X, 6, 6P, 7, and 9.
* Max. ambient for explosionproof (EF) is 125F (52C)
(To order, add prefix °∞EF°± to catalog number.
All others: 32F to 104F (0C to 40C)
See Optional Features Section for other available options.
Refer to Engineering Section for details.
Approvals
CSA certified. UL listed General Purpose Valves.
Meets applicable CE directives.
Installation
For optimum life, the valve should be installed with the
solenoid positioned upright and vertical.
Refer to Engineering Section for details.
