ASCO RedHat Solenoid Valves 3-Way Solenoid Valves D8260 Series

Plastic Body – 1/4″
Direct acting valve available in a normally closed construction. Available AC or DC operated with plastic bodies designed to handle the challenges of harsh media.

Features
Corrosion-resistant plastic bodies
Available with compression fitting ends for metal or
plastic tube to save installation cost
Mountable in any position
Dispensing vending construction NSF 169 listed
Construction
Valve Parts in Contact with Fluids
Body CA, PA, PP
Seals and Disc NBR
Core Tube 305 Stainless Steel
Core and Plugnut 430F Stainless Steel
Springs 302 Stainless Steel
Shading Coil Copper
NC
Electrical
Spare Coil Part
Watt Rating and Power Consumption Number
Standard
AC General Purpose
Coil and
VA
Class of
DC Watts Watts VA Inrush AC DC
Holding
Insulation
B 6.4 6.5 9.2 17.3 174879 180555
F 10.6 6.1 16 30 238210 238310
Standard Voltages: 24, 120, 240, 480 volts AC, 60 Hz (or 110, 220 volts AC, 50 Hz).
6, 12, 24, 120, 240 volts DC. Must be specified when ordering.
Other voltages available when required.
Solenoid Enclosures
Nominal Ambient Temp. Range:
Standard: Watertight, Types 1, 2, 3, 3S, 4, and 4X.
AC: 32F to 125F (0C to 52C)
Optional: Open Frame Solenoid, Junction Box enclosures.
DC: 32F to 104F (0C to 40C)
See Optional Features Section for descriptions on these options.
Refer to Engineering Section for details.
Approvals:
CSA certified. UL Recognized Component. Meets
applicable CE directives.
Refer to Engineering Section for details.
