ASCO RedHat Solenoid Valves 2-Way 291 Series

Compressed Natural Gas - 3/8” - 1” - Solenoid pilot operated piston valves for high-pressure CNG dispensing. Available in normally closed constructions with Stainless Steel bodies. Available in AC or DC.

Features
Rugged stainless steel valve with piston design built
to withstand pressure ratings over 5,000 psi
High flow design for fast CNG dispensing, reduces
vehicle fill time
Ambient temperature range -40!aF to 158F (-40C to 70C
PEEK piston provides tight sealing and
durable operation
Suitable for use in Class I, Div. 1 hazardous locations
Construction
Valve Parts in Contact with Fluids
Body 303 Stainless Steel
Core Tube Aluminum bronze
Piston PEEK
Core and Plugnut 430F Stainless Steel
Solenoid Enclosures
Springs 301 Stainless Steel
Explosionproof and Watertight, Types 3, 3S, 4, 4X, 6,
Sealing (U-cup) PTFE/302 Stainless Steel
6P, 7 and 9.
Seals FKM
Nominal Ambient Temp. Range
-40!aF to 158!aF (-40!aC to 70
Electrical
Approvals
Spare Coil
UL listed solenoid
Watt Rating and Power Consumption Part Number
Standard Coil
for hazardous locations -File E12264
ACExplosionproof
and Class of DC
CSA certified solenoid
WattsVA HoldingVA InrushACDC
Insulation
Watts
SPECIAL
for hazardous locations -File 1001265
F 11.6 12 12 12 276000 238714
SERVICE VALVES
Meets applicable CE directives
Standard Voltages:24/50-60, 115/50-60, 120/50-60, 200/50-60, 230/50-60, and
240/50-60 volts AC, or 6, 12, 24, 48, 110, 120 and 240 volts DC.
Options
Three and six-station manifolds available, consult factory.
Rebuild kits available, consult factory.
How to Order
8291G410H0100 FA
Valve Construction Voltage
Base Catalog Number
Electrical Interface
DC AC
Refer to the Specifications Chart
100 PEEK piston, FKM seals
H0 Explosionproof & Watertight
E7  6/DC FQ  24/50-60
 RHII, 1/2!± Conduit with Leads(18!±
F3  12/DC FC  115/50-60
H7 Explosionproof & Watertight,
F1  24/DC FA  120/50-60
 RHII, 1/2!± Conduit with Leads(72!±
F9  48/DC EL  200/50-60
FJ  110/DC FH  230/50-60
FD  120/DC E6  240/50-60
E2  240/DC
