Parker SOLENOID EXHAUST VALVES 72 SERIES SOLENOID VALVES
72EF21JSA
Description Value
PRODUCT TYPE Valve Solenoid
CONFIGURATION/TYPE 2-Way
OPERATION NC
MEDIA Air
PIPE/PORT SIZE 3/4"
MAX OPERATING PRESSURE DIFF 8 bar
ENCLOSURE DIN
VOLTAGE/FREQUENCY RATING 220 Volts AC
ORIFICE DIAMETER 25 mm
POWER CONSUMPTION 8 W
CONNECTION NPT
COIL INSULATION F
COIL TERMINATIONS DIN
BODY MATERIAL Aluminum
MIN OPERATING PRESSURE DIFF 1 bar
FLOW COEFFICIENT/RATING CV = 6,47
STANDARDS Pilot Operated
AMBIENT TEMPERATURE 50 ºC
FLUID TEMPERATURE 80 ºC
SEALS NBR
MOPD AIR/GAS 8 bar
ACTUATION Solenoid
Configurator NO
CAD Drawing Available NO
72EF21ZS-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72EF21ZSA-AC
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72EF21ZSAB
Description Value
PRODUCT TYPE Valve Solenoid
CONFIGURATION/TYPE 2-Way
OPERATION NC
MEDIA Air
PIPE/PORT SIZE 3/4"
MAX OPERATING PRESSURE DIFF 8 bar
ENCLOSURE DIN
VOLTAGE/FREQUENCY RATING 220 Volts AC
ORIFICE DIAMETER 25 mm
POWER CONSUMPTION 8 W
CONNECTION BSP
COIL INSULATION F
COIL TERMINATIONS DIN
BODY MATERIAL Aluminum
MIN OPERATING PRESSURE DIFF 1 bar
FLOW COEFFICIENT/RATING CV = 6,47
STANDARDS Pilot Operated
AMBIENT TEMPERATURE 50 ºC
FLUID TEMPERATURE 80 ºC
SEALS NBR
MOPD AIR/GAS 8 bar
ACTUATION Solenoid
Configurator NO
CAD Drawing Available NO
72EF21ZSB
Description Value
PRODUCT TYPE Valve Solenoid
CONFIGURATION/TYPE 2-Way
OPERATION NC
MEDIA Air
PIPE/PORT SIZE 3/4"
MAX OPERATING PRESSURE DIFF 8 bar
ENCLOSURE DIN
VOLTAGE/FREQUENCY RATING 110 Volts DC
ORIFICE DIAMETER 25 mm
POWER CONSUMPTION 8 W
CONNECTION BSP
COIL INSULATION F
COIL TERMINATIONS DIN
BODY MATERIAL Aluminum
MIN OPERATING PRESSURE DIFF 1 bar
FLOW COEFFICIENT/RATING CV = 6,47
STANDARDS Pilot Operated
AMBIENT TEMPERATURE 50 ºC
FLUID TEMPERATURE 80 ºC
SEALS NBR
MOPD AIR/GAS 8 bar
ACTUATION Solenoid
Configurator NO
CAD Drawing Available NO
72EF21ZSDB-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72EF21ZSH-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72EF210TF-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72EF210TFB-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72EF210TFX-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF21JSA-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF21ZS
Description Value
PRODUCT TYPE Valve Solenoid
CONFIGURATION/TYPE 2-Way
OPERATION NC
MEDIA Air
PIPE/PORT SIZE 1"
MAX OPERATING PRESSURE DIFF 8 bar
ENCLOSURE DIN
VOLTAGE/FREQUENCY RATING 110 Volts DC
ORIFICE DIAMETER 25 mm
POWER CONSUMPTION 8 W
CONNECTION NPT
COIL INSULATION F
COIL TERMINATIONS DIN
BODY MATERIAL Aluminum
MIN OPERATING PRESSURE DIFF 1 bar
FLOW COEFFICIENT/RATING CV = 12,9
STANDARDS Pilot Operated
AMBIENT TEMPERATURE 50 ºC
FLUID TEMPERATURE 80 ºC
SEALS NBR
MOPD AIR/GAS 8 bar
ACTUATION Solenoid
Configurator NO
CAD Drawing Available NO
72FF21ZS-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF21ZSA-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF21ZSAX-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF21ZSAXB-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF21ZSB-AClick to View Part
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF21ZSXB-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF21ZXX-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF210TF-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF210TFB-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF210TFX-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF210TH-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72FF214TFB-A
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
72GF26ZSB
Description Value
PRODUCT TYPE Valve Solenoid
CONFIGURATION/TYPE 2-Way
OPERATION NC
MEDIA Air
PIPE/PORT SIZE 1"
MAX OPERATING PRESSURE DIFF 8 bar
ENCLOSURE DIN
VOLTAGE/FREQUENCY RATING 110 Volts DC
ORIFICE DIAMETER 42 mm
POWER CONSUMPTION 8 W
CONNECTION BSP
COIL INSULATION F
COIL TERMINATIONS DIN
BODY MATERIAL Aluminum
MIN OPERATING PRESSURE DIFF 1 bar
FLOW COEFFICIENT/RATING CV = 32,9
STANDARDS Pilot Operated
AMBIENT TEMPERATURE 50 ºC
FLUID TEMPERATURE 80 ºC
SEALS NBR
MOPD AIR/GAS 8 bar
ACTUATION Solenoid
Configurator NO
CAD Drawing Available NO
72218BN4UN00N0D200C2Click to View Part
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
7322BFN00481865J3Click to View Part
Description Value
PRODUCT TYPE
Configurator NO
CAD Drawing Available NO
