| Type of construction |
with internal tie-rods |
| Operation |
double-acting |
| Materials |
end blocks / tube / body = AL rack = steel - rack guide shoe = acetal resin - pinion = hardened steel seals = NBR |
| Type of mounting |
threaded holes in the central body by means of Series 60 brackets |
| Bore |
ø 32, 40, 50, 63, 80, 100, 125 |
| Operating temperature |
0°C ÷ 80°C (with dry air - 20°C) |
| Standard rotation angles |
90°, 180°, 270°, 360° (others on request) |
| Bearings |
Ball bearings ( ø 32 mm teflon bronze guide) |
| Operating pressure |
1 ÷ 10 bar |
| Fluid |
clean air, without lubrication. If lubricated air is used, it is recommended to use oil ISOVG32. Once applied the lubrication should never be interrupted |
