MODEL SVS

SINGLE SOLENOID

MODEL SVS

These models incorporate a 4-way Single Solenoid Pilot Valve, air
return. A maintained electrical contact is required to move the rods
its full stroke. Breaking the electrical contact returns the rod to its
original position.

Models can be supplied with the rod normally retracted
(electrical contact will extend rod) or normally
extended (electrical contact will retract rod).

The standard solenoid operator, is the AAS
Splice box housing.

Bore Sizes Available: 1-1/8”, 1-1/2”, 2”, 2-1/2”, 3”, 4” & *5.
Voltages: 12, 24,120 & 240/60 AC and 6, 12 & 24VDC are
standard.

* 5” BORE AVAILABLE-Consult Factory for Details.

ROD NORMALLY RETRACTED MODEL SVSR

Energize solenoid to extend rod, de-energize solenoid to retract rod.

ROD NORMALLY EXTENDED MODEL SVSE

Energize solenoid to retract rod, de-energize solenoid to extend rod.

SHOWN WITH
SPLICE BOX HOUSING AAS
