SMC Specialty & Engineered Cylinder CH(D)SD, ISO Standard Hydraulic Cylinder, Nominal Pressure (10MPa)

CH series hydraulic cylinders are available in compact, round body, JIS or tie-rod types. Nominal pressure ranges from 3.5MPa to 16MPa. Bore sizes are available, depending on the series, from 20 to 160. Auto switches are available on most models.

• Projection area, weight, and overall length has been reduced when compared to the CH2 series
• Applicable bore sizes: 40mm, 50mm, 63mm, 80mm, 100mm
• Nominal pressure: 10 MPa
• Available in 25mm to 1000mm strokes depending on bore size selection
• Auto switch capable
