Non-Driven actuators are intended to be with either a screw or belt driven actuators, providing linear support over an extended width. Used in conjunction with the DLT/DLK

DLR Actuators are available in multiple configurations;

• Standard Carriage Length
• Multiple Extended Carriage Lengths
•

  	Details	Speed	Forces and Torques
  Product	Size	Speed Maximum [m/s]	Fx dynamic [N]	Fy dynamic [N]	Fz dynamic [N]	Mx dynamic [Nm]	My dynamic [Nm]	Mz dynamic [Nm]	Fx static [N]	Fy static [N]	Fz static [N]	Mx static [Nm]	My static [Nm]	Mz static [Nm]
  DLR 120 Extended Carriage 6 Split Rollers
  	120	4	-	900	1000	125	120	90	-	1100	1250	150	140	100
  DLR 160 Extended Carriage 6 Split Rollers
  	160	6	-	2000	2800	320	300	150	-	3000	3500	400	360	180
  DLR 200 Extended Carriage 6 Split Rollers
  	200	8	-	3100	4400	510	480	275	-	4400	4900	600	560	310
