Rotork Process Control Actuators SM-1700/SM-5000

SM-1700

• Torques from 50 to 200 ft.lb. (67 to 271 Nm)
• 90 to 120 degrees rotation
• Modulating Duty: 2,000 starts per hour
• Manual override standard
• Automatic torque limiting
• Self-locking drive system to hold in last position and prevent backdriving up to thrust rating
• AC input power (single and three phase) or DC input power versions
• Temperature range from -40° F to 185° F (-40° C to 85° C)

SM-5000

• Torques from150 to 12,500 ft. lb.(203 to 16950 Nm)
• 33 to 90 degrees rotation
• Modulating Duty: 2,000 starts per hour
• Manual override standard
• Automatic torque limiting
• Self-locking drive system to hold in last position and prevent backdriving up to thrust rating
• AC input power (single and three phase)
• Temperature range from -40° F to 185° F (-40° C to 85° C)
